Timeline
Souptik Samanta 🚀
added to the journal ago
mostly completed with the cad
today i did is added all inner parts not only the outer shell added space for ccables proper cooling and mountng holes and proper bom
like even the scews are included and worked a bit with the fw!
Souptik Samanta 🚀
added to the journal ago
I have made the fan working
Will add moutning place for the cm5 and this time did a render and a and made this fan model so i can later do the thermal sim so it can be a real product not just a diy thing
ts fan will blow directly on the cm5 what more shall i add?
20251113-1836-29.5590726
much time into learning render and sim
Souptik Samanta 🚀
added to the journal ago
i forgot to add the img in last one
sorry about that
here is it
.............................................................................................................................................................
Souptik Samanta 🚀
added to the journal ago
mostly did my cad with mounting and stuff
made my case as thin it could be and made it hv ventilation places the purple ones are not just a inward extrude its a whole diff body so air can flow and its purple js to show
i will also make mounts for display and measure out the hdmi cavble many ppl upon chcking it told me only issue i have is the hdmi cables maynot fit and a bit heating ..
thats the hdmi cable
next up is the airflow simulation then final assembly and pcb!!!
also after my next update i had scrapped it tbh its js too amty as i said
so i went with this futuristic looking sleek and slim design with purple panels dual as a ventilation place
i did some research too on kiosks and their using conditions
someone may like this article https://kioskindia.in/the-ultimate-guide-to-information-kiosks-in-india-choosing-the-right-manufacturer-and-system/
Souptik Samanta 🚀
added to the journal ago
Start with CAD
did few designs and i did the cad too
but i deleted it becasuse it was just too much big
also it looked like a atm lol
this is the drawing i did in paper too this is the one that looked like atm (this is discarded atm)
will go with more of a sleek look
Souptik Samanta 🚀
started Kiosk ago
